25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive

Send Inquiry

Request To Call Back

25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive

Name: 25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive
Brand: Noble Automation Controls
Price: 81000.0 INR
Availability: InStock

Price 81000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive Specification

Mounting Type
Panel Mount

Insulation Material
Polycarbonate

Humidity %
5% to 95%, Non-Condensing

Feature
Safe Torque-Off, Removable Control Module, Embedded EtherNet/IP, USB Configuration Port

Shape
Rectangular

Efficiency
Up to 97%

Connector Type
Screw Terminal

Power Factor
>= 0.98

Overheating Protection
Yes, with Inbuilt Sensor

IP Rating
IP20

Operating Temperature
-20C to +50C

Surface Finish
Matte

Product Type
AC Drive

Application
Motor Control, Industrial Automation

Protection Level
Overload, Short Circuit, Overvoltage, Undervoltage

Frequency (MHz)
50/60 Hz

Rated Voltage
380-480V AC

Energy Consumption
High Efficiency Operation

Output Type
AC

Color
White & Black

Dimension (L*W*H)
232 mm x 130 mm x 170 mm

Weight
10.2 kg

Input Voltage
380-480V AC

Size
Medium Drive

Phase
Three Phase

No Of Poles
N/A (Not Applicable for Drives)

Connection Type
Terminal & Network

Material
Plastic & Metal

Altitude
Up to 1000m without Derating

Motor Power Capacity
18.5 kW (25 HP)

Display Type
LCD

Noise Level
<70 dB(A)

Model Number
25B-D037N104

Control Method
V/Hz, Sensorless Vector, Closed Loop Vector

Communication Protocols
EtherNet/IP, DeviceNet, Modbus RTU

Braking Unit
Integrated

Cooling Method
Fan Cooled

Digital Inputs
5

Relay Outputs
1

Enclosure Type
Open (IP20)

Analog Inputs
2

25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
10 Minutes

About 25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive

The Allen-Bradley 25B-D037N104 is a PowerFlex 525 Adjustable Frequency AC Drive (VFD). The designation "BOX" typically indicates a brand-new, factory-sealed unit shipping in its original manufacturer packaging. [1, 2, 3, 4]

Technical Specifications

Series: PowerFlex 525
Voltage Class: 480V AC, 3-Phase
Output Current: 37 Amperes
Normal Duty Power: 25 HP (18.5 kW)
Heavy Duty Power: 20 HP (15 kW)
Filtering Option: No Filter (The 104 suffix denotes an IP20 NEMA/Open Type enclosure without an internal EMC filter, whereas 114 includes a filter)
Enclosure Type: IP20 NEMA / Open Type
Communication: Embedded EtherNet/IP and RS485 [1, 2, 3, 4, 5]

Procurement

If you are looking to purchase this specific unit, it is available across industrial automation platforms and marketplaces:

You can find new and open-box options on Walmart.
For verified replacement components, listing marketplaces like PLC Exchange stock similar PowerFlex 525 hardwares.
For custom industrial inquiries or bulk sourcing, platforms like IndiaMART list multiple series variants

Advanced Control for Industrial Efficiency

The PowerFlex 525 AC Drive leverages advanced motor control technologies to optimize performance in various industrial applications. Supporting V/Hz, sensorless vector, and closed loop vector modes, this drive ensures precise speed and torque control, enhancing the reliability and flexibility of machine operations.

Flexible Connectivity and Integration

With embedded communication protocols such as EtherNet/IP, DeviceNet, and Modbus RTU, seamless integration into existing automation networks is effortless. The drive also features a removable control module and a USB configuration port, simplifying setup and maintenance for system integrators and maintenance teams.

Safety and Protection Features

Designed with safety in mind, the PowerFlex 525 offers comprehensive protection mechanisms including Safe Torque-Off, overload, short-circuit, overvoltage, and undervoltage protection. These features help safeguard both equipment and operators while minimizing downtime and maximizing productivity.

FAQ's of 25B-D037N104 PowerFlex 525 18.5kW (25Hp) AC Drive:

Q: How do I configure the PowerFlex 525 (25B-D037N104) AC Drive for my application?

A: Configuration can be performed using the LCD display interface or via the USB configuration port. You can also use the embedded communication protocols (EtherNet/IP, DeviceNet, Modbus RTU) for remote setup. Refer to the user manual for detailed step-by-step configuration tailored to your motor and system requirements.

Q: What types of motors can the 25B-D037N104 PowerFlex 525 AC Drive control?

A: This drive supports three-phase AC motors with a power capacity up to 18.5 kW (25 HP). It is capable of operating in V/Hz, sensorless vector, and closed loop vector modes for precise motor control across various industrial automation tasks.

Q: When should the integrated braking unit be used?

A: The built-in braking unit is ideal for applications that demand rapid deceleration or controlled stopping of motors under load. It enhances operational safety and reduces mechanical wear, making it suitable for high-inertia or frequent stop/start processes.

Q: Where can I mount the PowerFlex 525 Drive, and what are the enclosure requirements?

A: This model is designed for panel mounting within control cabinets and features an open (IP20) enclosure. Ensure installation in environments with ambient temperatures between -20C and +50C and humidity conditions ranging from 5% to 95%, non-condensing.

Q: What is the process for integrating the PowerFlex 525 with automation networks?

A: The drive can be connected to automation systems through its embedded EtherNet/IP, DeviceNet, or Modbus RTU protocols. Wiring is accomplished using terminal or network connections, ensuring quick integration with PLCs and industrial controllers.

Q: How does the PowerFlex 525 benefit energy efficiency and operational cost savings?

A: Operating at up to 97% efficiency with a power factor 0.98, the drive ensures minimal energy loss and high-performance operation. This reduces energy costs and contributes to overall system sustainability in industrial applications.
